Series B.2 Faucets #B25230000

Single lever bath mixer for exposed installation #B25230000

Single lever bath mixer for exposed installation, B25230000010 connection type: s-union, centre distance 150 mm ± 20 mm, flow rate spout 17,2 l/min (3bar), flow rate hose connection 15,2 l/min (3bar), noise class II

Item may differ from picture. Decorations and accessories are not included.

Top Downloads

ceramic cartridge, non-return valve in the hose connection, normal spray, hose connection DN15, connection size DN15, diverter automatically reverts from hand shower to bath spout when turned off, recommended operating pressure 1 - 5 bar, chrome

Color

Data sheet

Variants

Color 10, connection type: s-union, centre distance 150 mm ± 20 mm, flow rate spout 17,2 l/min (3bar), flow rate hose connection 15,2 l/min (3bar), noise class II

B25230000010

Suitable accessories

	Hand shower 1jet 110			UV0650013
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain
	Hand shower 1jet 110 MinusFlow			UV0652013
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar)
	Hand shower 1jet 110			UV0650014
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, Chrome/Chrome
	Hand shower 1jet 110 MinusFlow			UV0652014
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar), Chrome/Chrome
	Hand shower 3jet 110			UV0650015
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning
	Hand shower 3jet 110 MinusFlow			UV0652015
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning, flow rate 9,0 l/min (3bar)
	Hand shower 3jet 110			UV0650016
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning
	Hand shower 3jet 110 MinusFlow			UV0652016
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning, flow rate 9,0 l/min (3bar)
	Hand shower 3jet Click! 120			UV0650017
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Rain, Pulse, Mono, click! - button to switch between spray modes
	Hand shower 3jet Click! 120 MinusFlow			UV0652017
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Rain, Pulse, Mono, click! - button to switch between spray modes, flow rate 9,0 l/min (3bar)
	Stick hand shower			UV0640001
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, round
	Stick hand shower MinusFlow			UV0642001
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar), round
	Stick hand shower			UV0640002
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, square
	Stick hand shower MinusFlow			UV0642002
	connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar), square
	Hand shower holder			UV0620001
	fixed holding position, for shower hoses with conical nut, material: plastic
	Shower hose			UV0610006
	twist-free nut, with conical hose nut, connection thread 12,7 mm (1/2")
	Shower hose			UV0610007
	twist-free nut, with conical hose nut, connection thread 12,7 mm (1/2")
	Shower hose			UV0610008
	twist-free nut, with conical hose nut, connection thread 12,7 mm (1/2")
	Hand shower holder			UV0620007
	for shower hoses with conical nut, material: brass, fixed holding position, round escutcheon

Downloads

File filter

Mounting instruction

Technical drawings (TIFF)

CAD drawings 3D (DWG)

CAD drawings 3D (DXF)

Flow rate chart (PDF)

Product images (TIFF)

Warranty terms and conditions

Product images (TIFF)

Documents (PDF)

Hint:

Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Upon request cut-out templates are available from Duravit. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customised installation scenarios, can only be taken from the finished ceramic piece.
