Series Faucet Accessories Faucets #UV0630008
wall outlet #UV0630008
Item may differ from picture. Decorations and accessories are not included.
Top Downloads
non-return valve in the hose connection, round escutcheon
Variants
select| Color 10, chrome, connection size DN15 | UV0630008010 | |||
Suitable accessories
|
Thermostatic shower mixer for concealed installation | C14200015 | ||
| connection type: basic set for concealed installation, thermostatic cartridge, square escutcheon 150 x 150 mm, flow rate 20,6 l/min (3 bar), safety lock at 38°C, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, 1 outlet, with shut-off valve | ||||
|
Thermostatic shower mixer for concealed installation | C14200016 | ||
| connection type: basic set for concealed installation, thermostatic cartridge, round escutcheon Ø 170 mm, flow rate 20,6 l/min (3 bar), safety lock at 38°C, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, 1 outlet, with shut-off valve | ||||
|
Single lever shower mixer for concealed installation | C14210009 | ||
| connection type: basic set for concealed installation, ceramic cartridge, 1 outlet, square escutcheon 150 x 150 mm, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar | ||||
|
Single lever shower mixer for concealed installation | C14210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, 1 outlet, round escutcheon Ø 170 mm, flow rate 24,6 l/min (3 bar), includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar | ||||
|
Single lever shower mixer for concealed installation | TU4210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, 1 outlet, round escutcheon Ø 170 mm, flow rate 24 l/min (3 bar), includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar | ||||
|
Hand shower 1jet 110 | UV0650013 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain | ||||
|
Hand shower 1jet 110 MinusFlow | UV0652013 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar) | ||||
|
Hand shower 3jet 110 | UV0650015 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning | ||||
|
Hand shower 3jet 110 MinusFlow | UV0652015 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning, flow rate 9,0 l/min (3bar) | ||||
|
Hand shower 3jet 110 MinusFlow | UV0652016 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning, flow rate 9,0 l/min (3bar) | ||||
|
Hand shower 3jet Click! 120 | UV0650017 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Rain, Pulse, Mono, click! - button to switch between spray modes | ||||
|
Stick hand shower | UV0640001 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, round | ||||
|
Stick hand shower | UV0640002 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, square | ||||
|
Single lever shower mixer for concealed installation | MH4210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, 1 outlet, square escutcheon 150 x 150 mm, flow rate 24,6 l/min (3 bar), includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar | ||||
|
Single lever shower mixer for concealed installation | WA4210010 | ||
Suitable accessories for #UV0630008010
|
Single lever shower mixer for concealed installation | B14210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, round escutcheon Ø 170 mm, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, chrome | ||||
|
Single lever shower mixer for concealed installation | B24210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, round escutcheon Ø 170 mm, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, chrome | ||||
|
Single lever shower mixer for concealed installation | DE4210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, round escutcheon Ø 170 mm, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, chrome | ||||
|
Single lever shower mixer for concealed installation | WT4210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, round escutcheon Ø 170 mm, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, chrome | ||||
|
Single lever shower mixer concealed set | N14210007 | ||
| ceramic cartridge, 1 outlet, connection type: basic set for concealed installation, Complete set including basic set for concealed installation, chrome | ||||
|
Hand shower 1jet 110 | UV0650014 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, Chrome/Chrome | ||||
|
Hand shower 1jet 110 MinusFlow | UV0652014 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar), Chrome/Chrome | ||||
|
Hand shower 3jet 110 | UV0650016 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Soft Rain, Rain, Intense Rain, spray mode adjustment by turning | ||||
|
Stick hand shower MinusFlow | UV0642002 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar), square | ||||
|
Single lever shower mixer for concealed installation | CE4210007 | ||
| ceramic cartridge, 1 outlet, connection type: basic set for concealed installation, Complete set including basic set for concealed installation | ||||
|
Single lever shower mixer for concealed installation | WA4210007 | ||
| ceramic cartridge, 1 outlet, connection type: basic set for concealed installation, Complete set including basic set for concealed installation | ||||
|
Single lever shower mixer for concealed installation | MH4210007 | ||
| ceramic cartridge, 1 outlet, connection type: basic set for concealed installation, Complete set including basic set for concealed installation | ||||
|
Single lever shower mixer for concealed installation | N14210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, round escutcheon Ø 170 mm, includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar, chrome | ||||
|
Single lever shower mixer for concealed installation | CE4210010 | ||
| connection type: basic set for concealed installation, ceramic cartridge, 1 outlet, round escutcheon Ø 170 mm, flow rate 24,6 l/min (3 bar), includes: visible parts with functional unit, recommended operating pressure 1 - 5 bar | ||||
Suitable accessories
|
Hand shower 3jet Click! 120 MinusFlow | UV0652017 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray modes: Rain, Pulse, Mono, click! - button to switch between spray modes, flow rate 9,0 l/min (3bar) | ||||
|
Stick hand shower MinusFlow | UV0642001 | ||
| connection thread 12,7 mm (1/2"), silicon naps for easy cleaning, spray mode: Rain, flow rate 9,0 l/min (3bar), round | ||||
Downloads
Hint:
Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Upon request cut-out templates are available from Duravit. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customised installation scenarios, can only be taken from the finished ceramic piece.
Instructions
Product documentation
