Series Faucet Accessories Faucets #UV0642002

Stick hand shower 1jet MinusFlow #UV0642002

Design by Duravit

Stick hand shower 1jet MinusFlow, UV0642002010 Rain, Chrome

Item may differ from picture. Decorations and accessories are not included.

Top Downloads

MinusFlow, Flow rate (3 bar): 9 l/min, Silicone nubs

Dimension

Color

Data sheet

Variants

select

Color 10, Rain, Chrome

212x23 mm

0.180 kg

UV0642002010

Suitable accessories

	Dimension	Weight	Order number
Single lever bathtub mixer for exposed installation		2.35 kg	C15230000
Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter valve, Noise class: II
Bathtub thermostat for exposed installation		2.55 kg	C15220000
Thermostat cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Safety lock at 38 °C, Diverter valve, Non-return valve in the hose connection, Shut-off and diverter valve, Noise class: II
Single lever bathtub mixer for exposed installation		3.9 kg	TU5230000
Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter valve
Shower rail 900		0.385 kg	UV0600004
100 mm, Hand shower holder: height adjustable
wall outlet		0.3 kg	UV0630010
Square, Non-return valve: Individually, in the hose connection, Escutcheon shape: Square, Hand shower holder: Fixed
wall outlet		0.27 kg	UV0630011
Square, Non-return valve: Individually, in the hose connection, Escutcheon shape: Square
Hand shower holder		0.04 kg	UV0620001
Material: ABS, Hand shower holder: Fixed, Mounting bracket shape: Conical
Shower hose		0.28 kg	UV0610006
Rotation lock: Yes, Nut shape: Conical, 1250 mm
Shower hose		0.345 kg	UV0610007
Rotation lock: Yes, Nut shape: Conical, 1600 mm
Shower hose		0.37 kg	UV0610008
Rotation lock: Yes, Nut shape: Conical, 1800 mm
Bathtub thermostat for exposed installation		2.58 kg	WA5220000
Water connection: S-connections, 12,7 mm, Centre distance: 150 mm ± 15 mm, Thermostat cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Safety lock at 38 °C, Diverter valve, Non-return valve in the hose connection, Shut-off and diverter valve, Flow rate (3 bar): 18 l/min
Single lever bathtub mixer for exposed installation		1.7 kg	WA5230000
Water connection: S-connections, 12,7 mm, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter automatically reverts from hand shower to bath spout when turned off
Single lever bathtub mixer for exposed installation		2.57 kg	MH5230000
Water connection: 12,7 mm, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve

Suitable accessories for #UV0642002010

	Dimension	Weight	Order number
Single lever bathtub mixer for exposed installation		1.6 kg	B15230000
Chrome, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter automatically reverts from hand shower to bath spout when turned off, Noise class: II
Single lever bathtub mixer for exposed installation		1.68 kg	B25230000
Chrome, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter automatically reverts from hand shower to bath spout when turned off, Noise class: II
Single lever bathtub mixer for exposed installation		1.41 kg	DE5230000
Chrome, Water connection: 12,7 mm, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter automatically reverts from hand shower to bath spout when turned off, Flow rate (3 bar): 20,9 l/min
Single lever bathtub mixer for exposed installation		1.3 kg	N15230000
Chrome, Water connection: S-connections, 12,7 mm, Centre distance: 150 mm ± 10 mm, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Diverter automatically reverts from hand shower to bath spout when turned off
Stick hand shower 1jet		0.18 kg	UV0640002
Silicone nubs
Shower rail 700		0.32 kg	UV0600003
mm, Hand shower holder: height adjustable
wall outlet		0.28 kg	UV0630008
Round, Non-return valve: Individually, in the hose connection, Escutcheon shape: Round, Hand shower holder: Fixed
wall outlet		0.3 kg	UV0630009
Round, Non-return valve: Individually, in the hose connection, Escutcheon shape: Round
Single lever bathtub mixer for exposed installation		2.23 kg	CE5230000
Water connection: 12,7 mm, Ceramic cartridge, recommended operating pressure: 1 - 5 bar, Spray mode: Normal spray, Diverter valve, Non-return valve in the hose connection, Diverter valve

Suitable accessories for #UV0642002046

	Dimension	Weight	Order number
Hand shower holder		0.3 kg	UV0620007
Material: Brass, Hand shower holder: Fixed, Escutcheon shape: Round, Mounting bracket shape: Conical
Hand shower holder		0.32 kg	UV0620026
Material: Brass, Hand shower holder: Fixed, Escutcheon shape: Square, Mounting bracket shape: Conical

Downloads

File filter

Mounting instruction

Technical drawings (TIFF)

Flow rate chart (PDF)

Product images (TIFF)

Warranty terms and conditions

Documents (PDF)

Hint:

Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Upon request cut-out templates are available from Duravit. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customised installation scenarios, can only be taken from the finished ceramic piece.
